Product Details
＋
- Part No: T1296
- Material: Polychloropren (neoprene)
- Colour: Black
- Number of teeth: 101
- Width (mm): 20
- Length (mm): 808
- Qty: 1pc
- PTFE-infused jackets to reduce frictional losses and tooth shear.
- High grade HNBR rubber for superior heat and contamination resistance.
- Premium tensile members providing maximum strength.
- Aramid reinforced nylon jackets and backsides increase durability and lifetime.
- Genuine warranty equal to OE replacement interval.
- Suitable with:
- HYUNDAI
- ATOS
- Petrol 1L/41KW 1.0 i G4HC IL44,MX Front-Wheel Drive Hatchback (02/98-03/02)
- Petrol 1.1L/45KW 1.1 G4HG IL44,MX Front-Wheel Drive Hatchback (06/03-12/10)
- Petrol 1.1L/43KW 1.1 G4HD IL44,MX Front-Wheel Drive Hatchback (08/03-12/08)
- ATOZ
- Petrol 1L/43KW 1.0 i G4HC IL44,MX Front-Wheel Drive Hatchback (03/01-07/03)
- EON
- Petrol 0.8L/41KW 0.8 G3HA Front-Wheel Drive Hatchback (08/11-on)
- GETZ
- Petrol 1.1L/49KW 1.1 G4HG TB Front-Wheel Drive Hatchback (04/07-12/09)
- i10
- Petrol 1.1L/49KW 1.1 G4HG PA Front-Wheel Drive Hatchback (01/08-12/13)
- Petrol 1.1L/51KW 1.1 G4HG PA Front-Wheel Drive Hatchback (04/11-12/13)
- Petrol 1.1L/50KW 1.1 G4HG PA Front-Wheel Drive Hatchback (11/08-12/13)
- Petrol 1.1L/48KW 1.1 G4HG PA Front-Wheel Drive Hatchback (12/07-12/13)
- Caution:
- Before any service work on the belt is begun to be sure that the motor or engine is switched off and cannot be started.
- Important:
- Check for worn tensioners and idler pulleys. This is the best time to replace these part these parts if needed.
- Belt Removal:
- Loosen adjustment or pivot bolts.
- Move adjustment unit to minimum position.
- Remove belt.
- Belt Installation:
- Place new belt loosely on pulleys. Do not pry onto pulleys.
- Tension belt according to manufacturer's instruction.
- Run drive 5 minutes and retension. Belts must be tight enough to prevent slipping when drive is fully loaded.
